ADLINK COM-HPC-mPTL is a COM-HPC R1.3 Mini computer-on-module powered by the Intel Core Ultra Processor Series 3 “Panther Lake” family, up to the 180 TOPS 16-core Core Ultra X7 358H processor.The module supports up to 64GB LPDDR5x and optional NVMe SSD BGA storage, and features two 2.5GbE controllers, optional MIPI CSI camera connectors, and a 40-pin debug connector. All I/Os are exposed through a standard 400-pin high-density board-to-board connector, including four display interfaces (HDMI, DP, USB4, eDP), and up to 16x PCIe Gen4/Gen5 lanes.COM-HPC-mPTL specifications:
SoC – Intel Core Ultra Series 3 Panther Lake-H processors (one or the other)
Intel Core Ultra 5 325 8-core (4P+0E+4LPE) processor up to 2.1 GHz / 4.5 GHz (Turbo) with 12MB cache, 4-core Xe3 graphics (40 TOPS), 47 TOPS NPU; PBP: 25W
Intel Core Ultra 7 356H 16-core (4P+8E+4LPE) processor up to 1.9 GHz / 4.7 GHz (Turbo) with 18MB cache, 4-core Xe3 graphics (40 TOPS), 50 TOPS NPU; PBP: 25W
Intel Core Ultra X7 358H 16-core (4P+8E+4LPE) processor up to 1.9 GHz / 4.8 GHz (Turbo) with 18MB cache, 12-core Xe3 graphics (Arc B390, 122 TOPS), 50 TOPS NPU; PBP: 25W
