Last March, Gateworks introduced the Catalina SBC family, starting with the GW9200 board, based on NXP i.MX 95 SoC for industrial Edge AI applications, and featuring Flexible Socket Adapter (FSA) sockets to accommodate either mini PCIe or M.2 module adapters, depending on requirements.We missed the original announcement, but the new SBC family was brought to our attention when Ezurio announced the acquisition of Gateworks last week. The GW9200 board comprises a system-on-module with the NXP i.MX 95 chip, 4GB LPDDR5 and 8GB eMMC flash by default, as well as a carrier board with 10GbE and GbE RJ45 ports, a MIPI DSI/CSI display/camera interface, two FSA sockets for M.2 or mini PCIe expansion, and a range of I/Os.Ezurio/Gateworks Catalina GW9200 specifications:
SoC – NXP i.MX 95
Up to 6x Arm Cortex-A55 application cores clocked at 1.8 GHz with 32KB I-cache and D-cache, 64KB L2 cache, and 512KB L3 cache
1x Arm Cortex-M7 real-time core clocked at 800 MHz
1x Arm Cortex-M33 safety core clocked at 333 MHz
