Makerfabs MaTouch ESP32-P4 TFTTouch 10.1 MIPI with 4G LTE is an ESP32-P4 + ESP32-C6-based display development platform for HMI edge AI, and connected embedded applications. The development board features a 10.1-inch IPS LCD, very similar to those of Seeed Studio’s reTerminal D1001, Waveshare ESP32-P4-WIFI6-Touch-LCD, and CrowPanel Advanced 7-inch displays.However, what makes it unique compared to other devices is that it also features a SIM7670G 4G LTE modem with a SIM card slot, an RJ45 Ethernet jack, and a 2MP camera. The HMI display also comes with microphone and speaker connectors, a microSD card slot, various USB interfaces, lithium battery support, and two 2.54 mm pitch GPIO expansion headers exposing UART, I2C, SPI, and other peripheral interfaces. All these features make it suitable for HMI, edge AI, and connected embedded applications.Makerfabs MaTouch ESP32-P4 10.1-inch 4G LTE specifications:
SoC – Espressif Systems ESP32-P4NRW32
Dual-core 32-bit RISC-V HP (High-performance) CPU @ up to 400 MHz with AI instructions extension and single-precision FPU
Single-RISC-V LP (Low-power) MCU core @ up to 40 MHz
Memory
