Renesas RZ/G3L & RZ/G3SE - Ultra-low-power Cortex-A55 MPUs for industrial HMI and IoT applications - CNX Software

Renesas has expanded its RZ/G Series with the RZ/G3L and RZ/G3SE, two new 64-bit MPUs for HMI and IoT edge systems. Both devices integrate up to four Arm Cortex-A55 application cores clocked at up to 1.2 GHz and a 200 MHz Arm Cortex-M33 real-time coprocessor.The two chips are pin-to-pin compatible but target different applications. The RZ/G3L integrates an Arm Mali-G31 3D GPU and H.264 video codec for HMI applications like retail terminals and medical devices. The RZ/G3SE removes the GPU and video codec and is designed for IoT devices with basic display requirements, including EV chargers and industrial gateway devices. Both can reduce standby power consumption to around 1 mW and resume operation quickly from deep standby, which is useful for devices that need to remain connected while consuming very little power.Renesas RZ/G3L and RZ/G3SE specifications:

MPU core

Quad-core or Dual-core Arm Cortex-A55 @ up to 1.2 GHz

Arm Cortex-M33 system management processor @ 200 MHz

GPU (RZ/G3L only)
