Geniatech XPI-3576-CM5 is a Rockchip RK3576 octa-core Arm Cortex-A72/A53 system-on-module based on the Raspberry Pi CM4/CM5 form factor with up to 16GB LPDDR5 and 128GB eMMC flash.The module also features a RealTek RTL8211F Gigabit Ethernet controller, an Ampak AP6275S wireless module for dual-band WiFi 6 and Bluetooth 5.3 connectivity, and a Rockchip RK806S-5 PMIC for power management. It features two 100-pin B2B connectors, allowing it to be plugged into carrier boards designed for the Raspberry Pi CM4/CM5, with some limitations as we’ll see further below.Geniatech XPI-3576-CM5 specifications
SoC – Rockchip RK3576
Octa-core CPU – 4x Cortex-A72 cores at 2.2GHz, 4x Cortex-A53 cores at 1.8GHz
GPU – Arm Mali-G52 MC3 GPU at 1 GHz with support for OpenGL ES 3.2, OpenCL 2.0, and Vulkan 1.1
NPU – 6 TOPS (INT8) AI accelerator with support for INT4/INT8/INT16/BF16/TF32 mixed operations.
