Designed by MuseLab, the nanoCH32H417 is a development board for the WCH CH32H417 dual-core RISC-V MCU, which we covered earlier this year for its USB 3.0 (5 Gbps), UHS, and Fast Ethernet support. At that time, only the official CH32H417 development board was available, but this board adds a third-party option.The board exposes various features of the MCU, including one USB 3.0 port, two USB Type-C ports, a 100Mbps Ethernet interface, and a MicroSD card slot. It also simplifies the prototyping workflow by integrating a WCHLink-E debugger directly onto the board, meaning you won’t need to wire up an external programmer to flash the MCU or view serial output.MuseLab nanoCH32H417 specifications:
MCU – WCH CH32H417QEU6
QingKe RISC-V5F up to 400 MHz
QinKe RISC-V3F up to 144 MHz
GPU – Graphics Processing Hardware Accelerator GPHA
